HELIX M FOUR DSP - 4 Channel Amplifier | 10ch DSP

The M FOUR DSP is more than “just” another four-channel amplifier – rather, despite its small dimensions, you are dealing with a powerful control center that has not less than a total of ten processed DSP channels. In addition, the amplifier delivers plentiful output power with generously 100 Watts RMS per channel into both 4 Ohms and 2 Ohms load.

Finally, its awesome price-performance ratio in combination with the fantastic feature set will ensure bright eyes.

Tonally absolutely HELIX!

Compromises in terms of sound quality have no place in a HELIX product – and that's why the M FOUR DSP is equipped with all the finesse for the perfect sound.

Maximum flexibility

Even the internal amplifier section of the M FOUR DSP is extremely variable – it can either be operated in 4-channel mode or, thanks to its bridging capability, can also be configured as a 3-channel or even 2-channel amplifier.

Virtual Channel Processing – that´s how signal routing works today

Many DSP channels need to be managed and configured properly – so there was no question that the M FOUR DSP is also equipped with Audiotec Fischer's innovative virtual channel processing.

The plus in speed – thanks to ACO

Faster is better – the particularly powerful 32 Bit ACO platform takes over all control tasks and ensures significantly more speed, especially for data communication with the DSP PC-Tool software but also for the lightning-fast switching between up to ten sound setups.

Compact, cool and absolutely practical

Despite its vast range of functions and huge output power the M FOUR DSP presents itself in the same classic, compact HELIX design with distinctive lines like a HELIX M FOUR or M ONE. Thanks to its Class D amplifier technology, it keeps a "cool head" even at full power.

FEATURES:

• Up to 135 Watts RMS max. output power per channel into 4 & 2 Ω
• Extremely powerful 64 Bit “fixed point” Audio DSP and state-of-the-art 32 Bit AD and DA signal converters from AKM
• ACO – Advanced 32 Bit CoProcessor platform for enhanced system and DSP features like:
• ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals
• SFX sound effects – Augmented Bass Processing, StageXpander, RealCenter & Co.
• Smart 6-channel high-level input with ADEP.3 circuit
• Six RCA / Cinch line outputs with max. 6 Volts output voltage
• Virtual Channel Processing (VCP) allows even more flexible configuration for highly complex sound systems
• Bridgeable amplifier channels for driving powerful woofer or subwoofer
• DSP-board manufactured in Germany

SPECIFICATIONS:

• Channels: 4 Channel
• Built-in DSP: Yes
• RCA Input: 6x RCA
• High-Level Input: 6x High level
• Power W RMS/ch Bridge: 200
• Power W RMS/ch | 4Ω: 100
• Power W RMS/ch | 2Ω: 135
• Other Input: Optical
• Class: D
• Max Input Sensitivity (V): 20
• Operational Voltage:
• RCA Out: 6x RCA
• Product Depth | mm: 154
• Product Width | mm: 230
• Product Height | mm: 50
