ZAPCO ST-68XDSP 4CH CLASS AB MINI AMPLIFIER WITH 8CH DSP

Features:

• 4-Channel, Full Range, Class A/B
• On-Board, Full Function, 8-ch. Digital Signal Processing
• High-pass and low-pass filters, phase control, signal delay, and 15 channels of parametric equalization on each channel
• Optical Digital Input
• BT Streaming: Bluetooth Port for external APTX HD Module (optional)
  • Supports the HD-BT Bluetooth direct comms port for high quality APTX HD connection
• Analog input gain controls

Specifications:

• Power @ 4Ω: 4 x 25 watts
• THD @ Rated Power  < 0.5% THD
• Power @ 2Ω: 4 x 35 watts
• Power (Max): 4 x 70W
• Signal to Noise Ratio > 90dB
• THD + Noise < 0.2%
• Channel Separation  >60dB
• Frequency Response 15Hz to 30KHz ±1dB
• Dimensions in mm: 160(W) x 57(H) x 131(L) Overall: 160(W) x 57(H) x 156(L)

Software Download:

PC Software
Windows PC > ST-68X DSP v.1.01
